ITT Cannon, LLC FRCIR08F-16A-10SW-F80-T109
- Mfg. Part Number
- FRCIR08F-16A-10SW-F80-T109
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 10POS INLINE SKT RA
- Datasheet Download
- FRCIR08F-16A-10SW-F80-T109.pdf
Availability of FRCIR08F-16A-10SW-F80-T109
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 153.52720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FRCIR08F-16A-10SW-F80-T109, we specialize in ITT Cannon, LLC all series electronic components. FRCIR08F-16A-10SW-F80-T109 can be shipped within 24 hours after order. If you have any demands for FRCIR08F-16A-10SW-F80-T109, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FRCIR08F-16A-10SW-F80-T109 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FRCIR08F-16A-10SW-F80-T109
| Internal Part Number | EIS-FRCIR08F-16A-10SW-F80-T109 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-5015, CIR | |
| Packaging | Bulk | |
| Connector Type | Plug, Female Sockets | |
| Number of Positions | 10 | |
| Shell Size - Insert | 16-A10 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line), Right Angle | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | W | |
| Ingress Protection | Environment Proof | |
| Shell Material, Finish | Aluminum Alloy, Black Zinc Cobalt Plated | |
| Contact Finish | Gold | |
| Features | Cable Clamp, Flame Retardant | |
| Contact Finish Thickness | - | |
| Current Rating | 7.5A | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FRCIR08F-16A-10SW-F80-T109 | |
| Related Links | FRCIR08F-16A-, FRCIR08F-16A-10SW-F80-T109 Datasheet, ITT Cannon, LLC Distributor | |
