Fairchild Semiconductor FSL116LR
- Mfg. Part Number
- FSL116LR
- Manufacturer
- Fairchild Semiconductor
- Product Category
- PMIC - AC DC Converters, Offline Switchers
- Brief Description
- IC PWM/SENSEFET SMPS 1A 8-DIP
- Datasheet Download
- FSL116LR.pdf
Availability of FSL116LR
Available Quantity
7360 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.42240
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FSL116LR, we specialize in Fairchild Semiconductor all series electronic components. FSL116LR can be shipped within 24 hours after order. If you have any demands for FSL116LR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FSL116LR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FSL116LR
| Internal Part Number | EIS-FSL116LR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Multiple Device Assembly Test 16/Jul/2013 | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - AC DC Converters, Offline Switchers | |
| Series | FPS™ | |
| Packaging | Tube | |
| Output Isolation | Isolated | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 650V | |
| Topology | Flyback | |
| Voltage - Start Up | 12V | |
| Voltage - Supply (Vcc/Vdd) | 8 V ~ 26 V | |
| Duty Cycle | 77% | |
| Frequency - Switching | 50kHz | |
| Power (Watts) | 16W | |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit | |
| Control Features | - | |
| Operating Temperature | -40°C ~ 105°C (TA) | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-DIP | |
| Mounting Type | Through Hole | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FSL116LR | |
| Related Links | FSL1, FSL116LR Datasheet, Fairchild Semiconductor Distributor | |
FSL116LR Details Description
