Omron G6A-274P-ST40-US-DC24
BYOMR,-G6A-274P-ST40-US-DC24.jpg)
- Mfg. Part Number
- G6A-274P-ST40-US-DC24
- Manufacturer
- Omron
- Product Category
- Signal Relays, Up to 2 Amps
- Brief Description
- RELAY GEN PURPOSE DPDT 2A 24V
- Datasheet Download
- G6A-274P-ST40-US-DC24.pdf
Availability of G6A-274P-ST40-US-DC24
Available Quantity
6837 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.07381
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of G6A-274P-ST40-US-DC24, we specialize in Omron all series electronic components. G6A-274P-ST40-US-DC24 can be shipped within 24 hours after order. If you have any demands for G6A-274P-ST40-US-DC24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- G6A-274P-ST40-US-DC24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
G6A-274P-ST40-US-DC24
| Internal Part Number | EIS-G6A-274P-ST40-US-DC24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Medical Solutions | |
| Standard Package | 500 | |
| Category | Relays | |
| Family | Signal Relays, Up to 2 Amps | |
| Series | G6A | |
| Packaging | Tube | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 16.7mA | |
| Coil Voltage | 24VDC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 2A | |
| Switching Voltage | 250VAC, 220VDC - Max | |
| Turn On Voltage (Max) | 16.8 VDC | |
| Turn Off Voltage (Min) | 2.4 VDC | |
| Operate Time | 5ms | |
| Release Time | 3ms | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver (Ag), Gold (Au) | |
| Coil Power | 400 mW | |
| Coil Resistance | 1.44 kOhms | |
| Operating Temperature | -40°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | G6A-274P-ST40-US-DC24 | |
| Related Links | G6A-274P-S, G6A-274P-ST40-US-DC24 Datasheet, Omron Distributor | |
G6A-274P-ST40-US-DC24 Details Description
