Omron G6K-2F-RF-TR09DC5
- Mfg. Part Number
- G6K-2F-RF-TR09DC5
- Manufacturer
- Omron
- Product Category
- Signal Relays, Up to 2 Amps
- Brief Description
- RELAY RF DPDT 1A 5V
- Datasheet Download
- G6K-2F-RF-TR09DC5.pdf
Availability of G6K-2F-RF-TR09DC5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 14.20139
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of G6K-2F-RF-TR09DC5, we specialize in Omron all series electronic components. G6K-2F-RF-TR09DC5 can be shipped within 24 hours after order. If you have any demands for G6K-2F-RF-TR09DC5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- G6K-2F-RF-TR09DC5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
G6K-2F-RF-TR09DC5
| Internal Part Number | EIS-G6K-2F-RF-TR09DC5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| PCN Assembly/Origin | G6K(U)-2x(-Y) Product Code 01/Apr/2013 | |
| Standard Package | 900 | |
| Category | Relays | |
| Family | Signal Relays, Up to 2 Amps | |
| Series | G6K-RF | |
| Packaging | Tape & Reel (TR) | |
| Relay Type | RF | |
| Coil Type | Non Latching | |
| Coil Current | 21.1mA | |
| Coil Voltage | 5VDC | |
| Contact Form | DPDT (2 Form C) | |
| Contact Rating (Current) | 1A | |
| Switching Voltage | 125VAC, 60VDC - Max | |
| Turn On Voltage (Max) | 4 VDC | |
| Turn Off Voltage (Min) | 0.5 VDC | |
| Operate Time | 3ms | |
| Release Time | 3ms | |
| Features | 1 GHz | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Contact Material | Silver (Ag), Gold (Au) | |
| Coil Power | 100 mW | |
| Coil Resistance | 237 Ohms | |
| Operating Temperature | -40°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | G6K-2F-RF-TR09DC5 | |
| Related Links | G6K-2F-R, G6K-2F-RF-TR09DC5 Datasheet, Omron Distributor | |
