Omron G6Z-1F DC9
- Mfg. Part Number
- G6Z-1F DC9
- Manufacturer
- Omron
- Product Category
- Signal Relays, Up to 2 Amps
- Brief Description
- RELAY RF SPDT 10MA 9V
- Datasheet Download
- G6Z-1F DC9.pdf
Availability of G6Z-1F DC9
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of G6Z-1F DC9, we specialize in Omron all series electronic components. G6Z-1F DC9 can be shipped within 24 hours after order. If you have any demands for G6Z-1F DC9, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- G6Z-1F DC9 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
G6Z-1F DC9
| Internal Part Number | EIS-G6Z-1F DC9 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| PCN Obsolescence/ EOL | G6Z Series Mar/2014 | |
| Standard Package | 50 | |
| Category | Relays | |
| Family | Signal Relays, Up to 2 Amps | |
| Series | G6Z | |
| Packaging | Tube | |
| Relay Type | RF | |
| Coil Type | Non Latching | |
| Coil Current | 22.2mA | |
| Coil Voltage | 9VDC | |
| Contact Form | SPDT (1 Form C) | |
| Contact Rating (Current) | 10mA | |
| Switching Voltage | 30VAC, 30VDC - Max | |
| Turn On Voltage (Max) | 6.75 VDC | |
| Turn Off Voltage (Min) | 0.9 VDC | |
| Operate Time | 10ms | |
| Release Time | 10ms | |
| Features | Sealed - Fully | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Contact Material | Copper (Cu), Gold (Au) | |
| Coil Power | 200 mW | |
| Coil Resistance | 405 Ohms | |
| Operating Temperature | -40°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | G6Z-1F DC9 | |
| Related Links | G6Z-1, G6Z-1F DC9 Datasheet, Omron Distributor | |
G6Z-1F DC9 Details Description
