Omron G8P-1A4TP DC5
- Mfg. Part Number
- G8P-1A4TP DC5
- Manufacturer
- Omron
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE SPST 30A 5V
- Datasheet Download
- G8P-1A4TP DC5.pdf
Availability of G8P-1A4TP DC5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of G8P-1A4TP DC5, we specialize in Omron all series electronic components. G8P-1A4TP DC5 can be shipped within 24 hours after order. If you have any demands for G8P-1A4TP DC5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- G8P-1A4TP DC5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
G8P-1A4TP DC5
| Internal Part Number | EIS-G8P-1A4TP DC5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| PCN Obsolescence/ EOL | G8P Series Nov/2014 | |
| Standard Package | 50 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | G8P | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 185mA | |
| Coil Voltage | 5VDC | |
| Contact Form | SPST-NO (1 Form A) | |
| Contact Rating (Current) | 30A | |
| Switching Voltage | 250VAC, 28VDC - Max | |
| Turn On Voltage (Max) | 3.75 VDC | |
| Turn Off Voltage (Min) | 0.5 VDC | |
| Operate Time | 15ms | |
| Release Time | 10ms | |
| Features | Insulation - Class F, Sealed - Fully | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin, Quick Connect - 0.250" (6.3mm) | |
| Contact Material | Silver Cadmium Oxide (AgCdO) | |
| Coil Power | 900 mW | |
| Coil Resistance | 27 Ohms | |
| Operating Temperature | -55°C ~ 105°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | G8P-1A4TP DC5 | |
| Related Links | G8P-1A, G8P-1A4TP DC5 Datasheet, Omron Distributor | |
G8P-1A4TP DC5 Details Description
