Sullins Connector Solutions GCB35DYRQ
- Mfg. Part Number
- GCB35DYRQ
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN CARD EXTEND .050" 35POS
- Datasheet Download
- GCB35DYRQ.pdf
Availability of GCB35DYRQ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.12100
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GCB35DYRQ, we specialize in Sullins Connector Solutions all series electronic components. GCB35DYRQ can be shipped within 24 hours after order. If you have any demands for GCB35DYRQ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GCB35DYRQ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GCB35DYRQ
| Internal Part Number | EIS-GCB35DYRQ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tube | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 35 | |
| Number of Positions | 70 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.050" (1.27mm) | |
| Features | Card Extender | |
| Mounting Type | Board Edge, Straddle Mount | |
| Termination | Solder | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Contact Type | Cantilever | |
| Color | Black | |
| Flange Feature | Straddle Mount Opening, Unthreaded, 0.078" (1.98mm) | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polyamide (PA9T) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GCB35DYRQ | |
| Related Links | GCB3, GCB35DYRQ Datasheet, Sullins Connector Solutions Distributor | |
