TE Connectivity Alcoswitch Switches GDH10S
- Mfg. Part Number
- GDH10S
- Manufacturer
- TE Connectivity Alcoswitch Switches
- Product Category
- DIP Switches
- Brief Description
- SWITCH DIP 10POS HALF PITCH SMD
- Datasheet Download
- GDH10S.pdf
Availability of GDH10S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GDH10S, we specialize in TE Connectivity Alcoswitch Switches all series electronic components. GDH10S can be shipped within 24 hours after order. If you have any demands for GDH10S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GDH10S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GDH10S
| Internal Part Number | EIS-GDH10S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | GDH10S Statement of Compliance | |
| 3D Model | 2-1437590-6.pdf | |
| Standard Package | 30 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | GDH | |
| Packaging | Tube | |
| Circuit | SPST | |
| Number of Positions | 10 | |
| Current Rating | 25mA | |
| Voltage Rating | 24VDC | |
| Actuator Type | Slide (Standard) | |
| Actuator Level | Flush, Recessed | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Height Above Board | 0.091" (2.30mm) | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Pitch | 0.050" (1.27mm), Half | |
| Washable | Yes | |
| Features | Tape Seal | |
| Body Material | Polyphenylene Sulfide (PPS) | |
| Length | 0.544" (13.82mm) | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 1,000 Cycles | |
| Electrical Life | 1,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GDH10S | |
| Related Links | GDH, GDH10S Datasheet, TE Connectivity Alcoswitch Switches Distributor | |
