Sullins Connector Solutions GEC07DRES
- Mfg. Part Number
- GEC07DRES
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 14POS .100 EYELET
- Datasheet Download
- GEC07DRES.pdf
Availability of GEC07DRES
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.23400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GEC07DRES, we specialize in Sullins Connector Solutions all series electronic components. GEC07DRES can be shipped within 24 hours after order. If you have any demands for GEC07DRES, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GEC07DRES Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GEC07DRES
| Internal Part Number | EIS-GEC07DRES | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tube | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 7 | |
| Number of Positions | 14 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.100" (2.54mm) | |
| Features | - | |
| Mounting Type | Panel Mount | |
| Termination | Solder Eyelet(s) | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Tin | |
| Contact Finish Thickness | 100µin (2.54µm) | |
| Contact Type | Full Bellows | |
| Color | Black | |
| Flange Feature | Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polyamide (PA9T) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GEC07DRES | |
| Related Links | GEC0, GEC07DRES Datasheet, Sullins Connector Solutions Distributor | |
GEC07DRES Details Description
