CW Industries GF-1326-0007
- Mfg. Part Number
- GF-1326-0007
- Manufacturer
- CW Industries
- Product Category
- Slide Switches
- Brief Description
- SWITCH SLIDE DPDT 13A 125V
- Datasheet Download
- GF-1326-0007.pdf
Availability of GF-1326-0007
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.92800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GF-1326-0007, we specialize in CW Industries all series electronic components. GF-1326-0007 can be shipped within 24 hours after order. If you have any demands for GF-1326-0007, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GF-1326-0007 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GF-1326-0007
| Internal Part Number | EIS-GF-1326-0007 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Switches | |
| Family | Slide Switches | |
| Series | GF | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Contact Timing | Not Specified | |
| Switch Function | On-On | |
| Current Rating | 13A (AC), 500mA (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 125V | |
| Actuator Type | Standard | |
| Actuator Length | 8.74mm | |
| Contact Material | Copper | |
| Contact Finish | Silver | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Features | - | |
| Actuator Material | Polyamide (PA66), Nylon 6/6 | |
| Switch Travel | 4.01mm | |
| Operating Temperature | -10°C ~ 104°C | |
| Mechanical Life | 10,000 Cycles | |
| Electrical Life | 6,000 Cycles | |
| Operating Force | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GF-1326-0007 | |
| Related Links | GF-132, GF-1326-0007 Datasheet, CW Industries Distributor | |
GF-1326-0007 Details Description
