Honeywell Sensing and Productivity Solutions GLEC24C
- Mfg. Part Number
- GLEC24C
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH TOP ROLLR PLNGR DPDT 120V
- Datasheet Download
- GLEC24C.pdf
Availability of GLEC24C
Available Quantity
5060 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 67.15020
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GLEC24C, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. GLEC24C can be shipped within 24 hours after order. If you have any demands for GLEC24C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GLEC24C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GLEC24C
| Internal Part Number | EIS-GLEC24C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Electromechanical Switch Technology | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | GLS | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-Mom | |
| Current Rating | 6A (AC), 550mA (DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 125V | |
| Actuator Type | Roller Plunger | |
| Mounting Type | Chassis Mount | |
| Termination Style | Screw Terminal | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | - | |
| Operating Force, Torque | 1315gf | |
| Release Force | - | |
| Pretravel | 0.120" (3.0mm) | |
| Differential Travel | 0.025" (0.6mm) | |
| Overtravel | 0.118" (3.0mm) | |
| Operating Position | 1.100" (28.0mm) | |
| Mechanical Life | 15,000,000 Cycles | |
| Electrical Life | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GLEC24C | |
| Related Links | GLE, GLEC24C Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
