Murata Electronics North America GRM2196P2A560JZ01D
.jpg)
- Mfg. Part Number
- GRM2196P2A560JZ01D
- Manufacturer
- Murata Electronics North America
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 56PF 100V P2H 0805
- Datasheet Download
- GRM2196P2A560JZ01D.pdf
Availability of GRM2196P2A560JZ01D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GRM2196P2A560JZ01D, we specialize in Murata Electronics North America all series electronic components. GRM2196P2A560JZ01D can be shipped within 24 hours after order. If you have any demands for GRM2196P2A560JZ01D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GRM2196P2A560JZ01D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GRM2196P2A560JZ01D
| Internal Part Number | EIS-GRM2196P2A560JZ01D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | GRM | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 56pF | |
| Tolerance | ±5% | |
| Voltage - Rated | 100V | |
| Temperature Coefficient | P2H | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.037" (0.95mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GRM2196P2A560JZ01D | |
| Related Links | GRM2196P2, GRM2196P2A560JZ01D Datasheet, Murata Electronics North America Distributor | |
