Schurter GSP1.8103.1
- Mfg. Part Number
- GSP1.8103.1
- Manufacturer
- Schurter
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- GSP1 APPLIANCE INLET 10A 70
- Datasheet Download
- GSP1.8103.1.pdf
Availability of GSP1.8103.1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.77500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of GSP1.8103.1, we specialize in Schurter all series electronic components. GSP1.8103.1 can be shipped within 24 hours after order. If you have any demands for GSP1.8103.1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- GSP1.8103.1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
GSP1.8103.1
| Internal Part Number | EIS-GSP1.8103.1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | GSP1.8.igsGSP1.8.stpGSP1.8.x_bGSP1.8.dxfGSP1.8.wrl | |
| PCN Packaging | Multiple Devices 20/Nov/2015 | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | GSP1 | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C14 | |
| Connector Type | Receptacle, Male Blades | |
| Current - IEC | 10A | |
| Voltage - IEC | 250VAC | |
| Current - UL | 15A | |
| Voltage - UL | 250VAC | |
| Filter Type | Unfiltered - Commercial | |
| Fuse | No | |
| Number of Positions | 3 | |
| Mounting Type | Panel Mount, Flange; Through Hole, Right Angle | |
| Termination | Quick Connect - 0.189" (4.8mm) | |
| Switch Features | - | |
| Features | - | |
| Fuse Holder, Drawer | - | |
| Panel Cutout Dimensions | Rectangular - 30.30mm x 22.50mm | |
| Panel Thickness | - | |
| Material Flammability Rating | UL94 V-0 | |
| Ingress Protection | IP40 | |
| Approvals | CCC, CSA, ENEC, UL | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | GSP1.8103.1 | |
| Related Links | GSP1., GSP1.8103.1 Datasheet, Schurter Distributor | |
