Fairchild Semiconductor H11L1M
- Mfg. Part Number
- H11L1M
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Optoisolators - Logic Output
- Brief Description
- OPTOISO 7.5KV OPN COLLECTOR 6DIP
- Datasheet Download
- H11L1M.pdf
Availability of H11L1M
Available Quantity
31557 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29768
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of H11L1M, we specialize in Fairchild Semiconductor all series electronic components. H11L1M can be shipped within 24 hours after order. If you have any demands for H11L1M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- H11L1M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
H11L1M
| Internal Part Number | EIS-H11L1M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Datasheet Update 11/Jun/2014 | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Logic Output | |
| Series | - | |
| Packaging | Tube | |
| Number of Channels | 1 | |
| Inputs - Side 1/Side 2 | 1/0 | |
| Voltage - Isolation | 7500Vpk | |
| Common Mode Transient Immunity (Min) | - | |
| Input Type | DC | |
| Output Type | Open Collector | |
| Current - Output / Channel | 50mA | |
| Data Rate | 1MHz | |
| Propagation Delay tpLH / tpHL (Max) | 4µs, 4µs | |
| Rise / Fall Time (Typ) | 100ns, 100ns | |
| Voltage - Forward (Vf) (Typ) | 1.2V | |
| Current - DC Forward (If) (Max) | 30mA | |
| Voltage - Supply | 3 V ~ 15 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Through Hole | |
| Package / Case | 6-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 6-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | H11L1M | |
| Related Links | H11, H11L1M Datasheet, Fairchild Semiconductor Distributor | |
