Micronas GmbH HAL501SF-A
- Mfg. Part Number
- HAL501SF-A
- Manufacturer
- Micronas GmbH
- Product Category
- Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs)
- Brief Description
- IC HALL EFFECT SWITCH UNI SOT89
- Datasheet Download
- HAL501SF-A.pdf
Availability of HAL501SF-A
Available Quantity
6020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.36315
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HAL501SF-A, we specialize in Micronas GmbH all series electronic components. HAL501SF-A can be shipped within 24 hours after order. If you have any demands for HAL501SF-A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HAL501SF-A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HAL501SF-A
| Internal Part Number | EIS-HAL501SF-A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Sensors, Transducers | |
| Family | Magnetic Sensors - Hall Effect, Digital Switch, Linear, Compass (ICs) | |
| Series | HAL® | |
| Packaging | Tape & Reel (TR) | |
| Sensing Range | 0.5mT Trip, -0.7mT Release | |
| Type | Bipolar Latch | |
| Voltage - Supply | 3.8 V ~ 24 V | |
| Current - Supply | 4.2mA | |
| Current - Output (Max) | 20mA | |
| Output Type | Open Collector | |
| Features | - | |
| Operating Temperature | -40°C ~ 170°C | |
| Package / Case | TO-243AA | |
| Supplier Device Package | TO-243AA (SOT-89) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HAL501SF-A | |
| Related Links | HAL50, HAL501SF-A Datasheet, Micronas GmbH Distributor | |
HAL501SF-A Details Description
