Panasonic Electric Works HC4-HTM-AC240V
- Mfg. Part Number
- HC4-HTM-AC240V
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE 4PDT 5A 240V
- Datasheet Download
- HC4-HTM-AC240V.pdf
Availability of HC4-HTM-AC240V
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HC4-HTM-AC240V, we specialize in Panasonic Electric Works all series electronic components. HC4-HTM-AC240V can be shipped within 24 hours after order. If you have any demands for HC4-HTM-AC240V, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HC4-HTM-AC240V Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HC4-HTM-AC240V
| Internal Part Number | EIS-HC4-HTM-AC240V | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | General Appl Guidelines Standards Chart How to Read Date Codes | |
| Standard Package | 20 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | HC | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 5mA | |
| Coil Voltage | 240VAC | |
| Contact Form | 4PDT (4 Form C) | |
| Contact Rating (Current) | 5A | |
| Switching Voltage | 250VAC - Max | |
| Turn On Voltage (Max) | 192 VAC | |
| Turn Off Voltage (Min) | 72 VAC | |
| Operate Time | 20ms | |
| Release Time | 20ms | |
| Features | - | |
| Mounting Type | Chassis Mount | |
| Termination Style | Plug In | |
| Contact Material | Silver Nickel (AgNi) | |
| Coil Power | 1.2 VA | |
| Coil Resistance | - | |
| Operating Temperature | -50°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HC4-HTM-AC240V | |
| Related Links | HC4-HTM, HC4-HTM-AC240V Datasheet, Panasonic Electric Works Distributor | |
HC4-HTM-AC240V Details Description
