Avago Technologies US, Inc. HCPL-5730#100
- Mfg. Part Number
- HCPL-5730#100
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISO 1.5KV 2CH DARL 8-SMD BJ
- Datasheet Download
- HCPL-5730#100.pdf
Availability of HCPL-5730#100
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 87.71444
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HCPL-5730#100, we specialize in Avago Technologies US, Inc. all series electronic components. HCPL-5730#100 can be shipped within 24 hours after order. If you have any demands for HCPL-5730#100, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HCPL-5730#100 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HCPL-5730#100
| Internal Part Number | EIS-HCPL-5730#100 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tube | |
| Number of Channels | 2 | |
| Voltage - Isolation | 1500VDC | |
| Current Transfer Ratio (Min) | 200% @ 5mA | |
| Current Transfer Ratio (Max) | - | |
| Turn On / Turn Off Time (Typ) | 2µs, 8µs | |
| Rise / Fall Time (Typ) | - | |
| Input Type | DC | |
| Output Type | Darlington | |
| Voltage - Output (Max) | 20V | |
| Current - Output / Channel | 40mA | |
| Voltage - Forward (Vf) (Typ) | 1.4V | |
| Current - DC Forward (If) (Max) | 10mA | |
| Vce Saturation (Max) | 110mV | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SMD Butt Joint | |
| Supplier Device Package | 8-SMD Butt Joint | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HCPL-5730#100 | |
| Related Links | HCPL-5, HCPL-5730#100 Datasheet, Avago Technologies US, Inc. Distributor | |
