Avago Technologies US, Inc. HEDM-5500#B12
- Mfg. Part Number
- HEDM-5500#B12
- Manufacturer
- Avago Technologies US, Inc.
- Product Category
- Encoders
- Brief Description
- KIT ENCODER 2CH 1000CPR 6MM
- Datasheet Download
- HEDM-5500#B12.pdf
Availability of HEDM-5500#B12
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 43.68960
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HEDM-5500#B12, we specialize in Avago Technologies US, Inc. all series electronic components. HEDM-5500#B12 can be shipped within 24 hours after order. If you have any demands for HEDM-5500#B12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HEDM-5500#B12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HEDM-5500#B12
| Internal Part Number | EIS-HEDM-5500#B12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Sensors, Transducers | |
| Family | Encoders | |
| Series | HEDM | |
| Encoder Type | Optical | |
| Output Type | Quadrature (Incremental) | |
| Pulses per Revolution | 1000 | |
| Voltage - Supply | 5V | |
| Actuator Type | 6mm Open Center | |
| Detent | No | |
| Built in Switch | No | |
| Mounting Type | Chassis Mount, Motors | |
| Orientation | Vertical | |
| Termination Style | Terminal Pins | |
| Rotational Life (Cycles Min) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HEDM-5500#B12 | |
| Related Links | HEDM-5, HEDM-5500#B12 Datasheet, Avago Technologies US, Inc. Distributor | |
HEDM-5500#B12 Details Description
