Hirose Electric Co Ltd HIF3BA-60P-2.54PFA-2(71)
- Mfg. Part Number
- HIF3BA-60P-2.54PFA-2(71)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HDR 60POS 2.54MM
- Datasheet Download
- HIF3BA-60P-2.54PFA-2(71).pdf
Availability of HIF3BA-60P-2.54PFA-2(71)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.83000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HIF3BA-60P-2.54PFA-2(71), we specialize in Hirose Electric Co Ltd all series electronic components. HIF3BA-60P-2.54PFA-2(71) can be shipped within 24 hours after order. If you have any demands for HIF3BA-60P-2.54PFA-2(71), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HIF3BA-60P-2.54PFA-2(71) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HIF3BA-60P-2.54PFA-2(71)
| Internal Part Number | EIS-HIF3BA-60P-2.54PFA-2(71) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | HIF3B | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 60 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Contact Mating Length | 0.236" (6.00mm) | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit, Solder | |
| Fastening Type | Latch Lock/Eject Hooks | |
| Features | Polarizing Key | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 8µin (0.20µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HIF3BA-60P-2.54PFA-2(71) | |
| Related Links | HIF3BA-60P-2, HIF3BA-60P-2.54PFA-2(71) Datasheet, Hirose Electric Co Ltd Distributor | |
HIF3BA-60P-2.54PFA-2(71) Details Description
