3M HM-H154APWR2-5AP1-TG30
- Mfg. Part Number
- HM-H154APWR2-5AP1-TG30
- Manufacturer
- 3M
- Product Category
- Backplane Connectors - Hard Metric, Standard
- Brief Description
- CONN HEADER HSHM 154POS 5ROW STR
- Datasheet Download
- HM-H154APWR2-5AP1-TG30.pdf
Availability of HM-H154APWR2-5AP1-TG30
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 29.08710
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HM-H154APWR2-5AP1-TG30, we specialize in 3M all series electronic components. HM-H154APWR2-5AP1-TG30 can be shipped within 24 hours after order. If you have any demands for HM-H154APWR2-5AP1-TG30, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HM-H154APWR2-5AP1-TG30 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HM-H154APWR2-5AP1-TG30
| Internal Part Number | EIS-HM-H154APWR2-5AP1-TG30 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Hard Metric, Standard | |
| Series | MetPak™ HM | |
| Packaging | Bulk | |
| Connector Type | Header, Male Pins | |
| Connector Style | A 22 | |
| Number of Positions | 154 (110 + 44 Ground + 4 Power) | |
| Number of Positions Loaded | All | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 5 + 2 | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Connector Usage | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Current Rating | 1A | |
| Voltage Rating | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HM-H154APWR2-5AP1-TG30 | |
| Related Links | HM-H154APWR, HM-H154APWR2-5AP1-TG30 Datasheet, 3M Distributor | |
HM-H154APWR2-5AP1-TG30 Details Description
