Fairchild Semiconductor HMA121FR2V
- Mfg. Part Number
- HMA121FR2V
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISO 3.75KV TRANSISTOR 4SMD
- Datasheet Download
- HMA121FR2V.pdf
Availability of HMA121FR2V
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HMA121FR2V, we specialize in Fairchild Semiconductor all series electronic components. HMA121FR2V can be shipped within 24 hours after order. If you have any demands for HMA121FR2V, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HMA121FR2V Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HMA121FR2V
| Internal Part Number | EIS-HMA121FR2V | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | PDN#Q1080165 17/Jan/2008 | |
| Standard Package | 2,500 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Voltage - Isolation | 3750Vrms | |
| Current Transfer Ratio (Min) | 100% @ 5mA | |
| Current Transfer Ratio (Max) | 600% @ 5mA | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 3µs, 3µs | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 80V | |
| Current - Output / Channel | 80mA | |
| Voltage - Forward (Vf) (Typ) | 1.3V (Max) | |
| Current - DC Forward (If) (Max) | 50mA | |
| Vce Saturation (Max) | 400mV | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SMD, Gull Wing | |
| Supplier Device Package | 4-Mini-Flat | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HMA121FR2V | |
| Related Links | HMA12, HMA121FR2V Datasheet, Fairchild Semiconductor Distributor | |
HMA121FR2V Details Description
