Hirose Electric Co Ltd HR08D-12WLPK-10S
- Mfg. Part Number
- HR08D-12WLPK-10S
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG R/A10POS W/SKT SLDR
- Datasheet Download
- HR08D-12WLPK-10S.pdf
Availability of HR08D-12WLPK-10S
Available Quantity
5070 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 19.24000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HR08D-12WLPK-10S, we specialize in Hirose Electric Co Ltd all series electronic components. HR08D-12WLPK-10S can be shipped within 24 hours after order. If you have any demands for HR08D-12WLPK-10S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HR08D-12WLPK-10S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HR08D-12WLPK-10S
| Internal Part Number | EIS-HR08D-12WLPK-10S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | HR08D Series Introduction | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | HR08D | |
| Packaging | Tray | |
| Connector Type | Plug, Female Sockets | |
| Number of Positions | 10 | |
| Shell Size - Insert | 12 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line), Right Angle | |
| Termination | Solder Cup | |
| Fastening Type | Push-Twist | |
| Orientation | Keyed | |
| Ingress Protection | IP67/68 - Dust Tight, Waterproof | |
| Shell Material, Finish | Aluminum Alloy, Polyamide Resin and Zinc Alloy | |
| Contact Finish | Gold | |
| Features | Backshell | |
| Contact Finish Thickness | - | |
| Current Rating | 3A | |
| Voltage - Rated | 200VAC, 250VDC | |
| Operating Temperature | -20°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HR08D-12WLPK-10S | |
| Related Links | HR08D-12, HR08D-12WLPK-10S Datasheet, Hirose Electric Co Ltd Distributor | |
HR08D-12WLPK-10S Details Description
