FFF HW04508100J0G
- Mfg. Part Number
- HW04508100J0G
- Manufacturer
- FFF
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- 508 TB SPR PLU UP/SIDE
- Datasheet Download
- HW04508100J0G.pdf
Availability of HW04508100J0G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.67197
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of HW04508100J0G, we specialize in FFF all series electronic components. HW04508100J0G can be shipped within 24 hours after order. If you have any demands for HW04508100J0G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- HW04508100J0G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
HW04508100J0G
| Internal Part Number | EIS-HW04508100J0G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 120 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | HW | |
| Packaging | Bulk | |
| Type | Plug, Female Sockets | |
| Number of Positions | 4 | |
| Positions Per Level | 4 | |
| Number of Levels | 1 | |
| Pitch | 0.200" (5.08mm) | |
| Header Orientation | - | |
| Plug Wire Entry | 180° | |
| Termination Style | Screwless - Leg Spring, Push-In Spring | |
| Mounting Type | Free Hanging (In-Line) | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 10A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | 12-26 AWG | |
| Wire Gauge or Range - mm² | - | |
| Color | Gray | |
| Operating Temperature | -40°C ~ 115°C | |
| Contact Mating Finish | Tin | |
| Features | Retention Latches (Non-Wire Side) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | HW04508100J0G | |
| Related Links | HW0450, HW04508100J0G Datasheet, FFF Distributor | |
