International Rectifier (Infineon Technologies Americas Corp.) IR2156S
- Mfg. Part Number
- IR2156S
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- PMIC - Lighting, Ballast Controllers
- Brief Description
- IC CNTL BALLAST 600V 0.5A 14SOIC
- Datasheet Download
- IR2156S.pdf
Availability of IR2156S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IR2156S, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. IR2156S can be shipped within 24 hours after order. If you have any demands for IR2156S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IR2156S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IR2156S
| Internal Part Number | EIS-IR2156S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 55 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Lighting, Ballast Controllers | |
| Series | - | |
| Packaging | Tube | |
| Type | Ballast Controller | |
| Frequency | 36kHz ~ 44kHz | |
| Voltage - Supply | 10.5 V ~ 16.5 V | |
| Current - Supply | 10mA | |
| Current - Output Source/Sink | - | |
| Dimming | No | |
| Operating Temperature | -25°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Drawing Number | 21; 01-3063; S; 14 | |
| Mfr Reel Diameter | * | |
| Mfr Reel Tape Material | * | |
| Mfr Reel Tape Width | * | |
| Supplier Device Package | 14-SOICN | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IR2156S | |
| Related Links | IR2, IR2156S Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
IR2156S Details Description
