International Rectifier (Infineon Technologies Americas Corp.) IRF7805ZGPBF
- Mfg. Part Number
- IRF7805ZGPBF
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 30V 16A 8-SOIC
- Datasheet Download
- IRF7805ZGPBF.pdf
Availability of IRF7805ZGPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IRF7805ZGPBF, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. IRF7805ZGPBF can be shipped within 24 hours after order. If you have any demands for IRF7805ZGPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IRF7805ZGPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IRF7805ZGPBF
| Internal Part Number | EIS-IRF7805ZGPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) Discrete Power MOSFETs 40V and Below | |
| PCN Obsolescence/ EOL | Multiple Devices 25/Apr/2014 | |
| PCN Assembly/Origin | Backend Wafer Transfer 23/Oct/2013 | |
| Standard Package | 95 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | HEXFET® | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 16A (Ta) | |
| Rds On (Max) @ Id, Vgs | 6.8 mOhm @ 16A, 10V | |
| Vgs(th) (Max) @ Id | 2.25V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 27nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 2080pF @ 15V | |
| Power - Max | 2.5W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IRF7805ZGPBF | |
| Related Links | IRF780, IRF7805ZGPBF Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
