International Rectifier (Infineon Technologies Americas Corp.) IRG4IBC30S
- Mfg. Part Number
- IRG4IBC30S
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- IGBTs - Single
- Brief Description
- IGBT 600V 23.5A 45W TO220FP
- Datasheet Download
- IRG4IBC30S.pdf
Availability of IRG4IBC30S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IRG4IBC30S, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. IRG4IBC30S can be shipped within 24 hours after order. If you have any demands for IRG4IBC30S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IRG4IBC30S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IRG4IBC30S
| Internal Part Number | EIS-IRG4IBC30S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | IGBTs - Single | |
| Series | - | |
| Packaging | Tube | |
| IGBT Type | - | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 23.5A | |
| Current - Collector Pulsed (Icm) | 68A | |
| Vce(on) (Max) @ Vge, Ic | 1.6V @ 15V, 18A | |
| Power - Max | 45W | |
| Switching Energy | 260µJ (on), 3.45mJ (off) | |
| Input Type | Standard | |
| Gate Charge | 50nC | |
| Td (on/off) @ 25°C | 22ns/540ns | |
| Test Condition | 480V, 18A, 23 Ohm, 15V | |
| Reverse Recovery Time (trr) | - | |
| Package / Case | TO-220-3 Full Pack | |
| Mounting Type | Through Hole | |
| Supplier Device Package | TO-220AB Full-Pak | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IRG4IBC30S | |
| Related Links | IRG4I, IRG4IBC30S Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
IRG4IBC30S Details Description
