International Rectifier (Infineon Technologies Americas Corp.) IRS2001STRPBF
- Mfg. Part Number
- IRS2001STRPBF
- Manufacturer
- International Rectifier (Infineon Technologies Americas Corp.)
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC DRIVER HI/LO SIDE 200V 8-SOIC
- Datasheet Download
- IRS2001STRPBF.pdf
Availability of IRS2001STRPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IRS2001STRPBF, we specialize in International Rectifier (Infineon Technologies Americas Corp.) all series electronic components. IRS2001STRPBF can be shipped within 24 hours after order. If you have any demands for IRS2001STRPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IRS2001STRPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IRS2001STRPBF
| Internal Part Number | EIS-IRS2001STRPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) | |
| PCN Assembly/Origin | Additional Test Site 07/Jan/2015 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Configuration | High and Low Side, Independent | |
| Input Type | Non-Inverting | |
| Delay Time | 160ns | |
| Current - Peak | 290mA | |
| Number of Configurations | 1 | |
| Number of Outputs | 2 | |
| High Side Voltage - Max (Bootstrap) | 200V | |
| Voltage - Supply | 10 V ~ 20 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IRS2001STRPBF | |
| Related Links | IRS200, IRS2001STRPBF Datasheet, International Rectifier (Infineon Technologies Americas Corp.) Distributor | |
IRS2001STRPBF Details Description
