Intersil ISL6700IR
- Mfg. Part Number
- ISL6700IR
- Manufacturer
- Intersil
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC DRIVER HALF BRIDGE DUAL 12QFN
- Datasheet Download
- ISL6700IR.pdf
Availability of ISL6700IR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISL6700IR, we specialize in Intersil all series electronic components. ISL6700IR can be shipped within 24 hours after order. If you have any demands for ISL6700IR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISL6700IR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISL6700IR
| Internal Part Number | EIS-ISL6700IR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 75 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | Half Bridge | |
| Input Type | PWM | |
| Delay Time | 70ns | |
| Current - Peak | 1.4A | |
| Number of Configurations | 1 | |
| Number of Outputs | 2 | |
| High Side Voltage - Max (Bootstrap) | 80V | |
| Voltage - Supply | 9 V ~ 15 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 12-VQFN Exposed Pad | |
| Supplier Device Package | 12-QFN (4x4) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISL6700IR | |
| Related Links | ISL6, ISL6700IR Datasheet, Intersil Distributor | |
ISL6700IR Details Description
