Intersil ISL8200MIRZ-T
- Mfg. Part Number
- ISL8200MIRZ-T
- Manufacturer
- Intersil
- Product Category
- DC DC Converters
- Brief Description
- IC BUCK SYNC ADJ 10A 23-QFN
- Datasheet Download
- ISL8200MIRZ-T.pdf
Availability of ISL8200MIRZ-T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 20.79660
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISL8200MIRZ-T, we specialize in Intersil all series electronic components. ISL8200MIRZ-T can be shipped within 24 hours after order. If you have any demands for ISL8200MIRZ-T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISL8200MIRZ-T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISL8200MIRZ-T
| Internal Part Number | EIS-ISL8200MIRZ-T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Application: Industrial Controls Power Module: ISL8200M Complete Current Share 10A DC/DC Module | |
| PCN Design/Specification | Mold Compound Update 26/Nov/2014 ISL8200MIRZ Multiple Changes 10/Jun/2015 | |
| Standard Package | 500 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 3V | |
| Voltage - Input (Max) | 20V | |
| Voltage - Output 1 | 0.6 ~ 6 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 10A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 23-QFN | |
| Size / Dimension | 0.59" L x 0.59" W x 0.09" H (15.0mm x 15.0mm x 2.2mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | - | |
| Power (Watts) - Max | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISL8200MIRZ-T | |
| Related Links | ISL820, ISL8200MIRZ-T Datasheet, Intersil Distributor | |
ISL8200MIRZ-T Details Description
