Texas Instruments ISO721MMDREP
- Mfg. Part Number
- ISO721MMDREP
- Manufacturer
- Texas Instruments
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 4KV 1CH GEN PURP 8SOIC
- Datasheet Download
- ISO721MMDREP.pdf
Availability of ISO721MMDREP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.63750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISO721MMDREP, we specialize in Texas Instruments all series electronic components. ISO721MMDREP can be shipped within 24 hours after order. If you have any demands for ISO721MMDREP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISO721MMDREP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISO721MMDREP
| Internal Part Number | EIS-ISO721MMDREP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Circuit Isolation Techniques | |
| Featured Product | ISO72x & ISO72xx Digital Isolators | |
| Manufacturer Product Page | ISO721MMDREP Specifications | |
| Standard Package | 2,500 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Technology | Capacitive Coupling | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 1 | |
| Inputs - Side 1/Side 2 | 1/0 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 4000Vpk | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Data Rate | 150Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 16ns, 16ns | |
| Pulse Width Distortion (Max) | 1ns | |
| Rise / Fall Time (Typ) | 1ns, 1ns | |
| Voltage - Supply | 3 V ~ 3.6 V, 4.5 V ~ 5.5 V | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISO721MMDREP | |
| Related Links | ISO721, ISO721MMDREP Datasheet, Texas Instruments Distributor | |
ISO721MMDREP Details Description
