XP Power ITX2405S
- Mfg. Part Number
- ITX2405S
- Manufacturer
- XP Power
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER +/-5V 6W
- Datasheet Download
- ITX2405S.pdf
Availability of ITX2405S
Available Quantity
5043 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.94000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ITX2405S, we specialize in XP Power all series electronic components. ITX2405S can be shipped within 24 hours after order. If you have any demands for ITX2405S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ITX2405S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ITX2405S
| Internal Part Number | EIS-ITX2405S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | ITX Series | |
| Standard Package | 20 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | ITX | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 18V | |
| Voltage - Input (Max) | 36V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 600mA, 600mA | |
| Power (Watts) - Manufacture Series | 6W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 8-SIP Module (7 Leads) | |
| Size / Dimension | 0.86" L x 0.36" W x 0.44" H (21.9mm x 9.2mm x 11.2mm) | |
| Operating Temperature | -40°C ~ 65°C | |
| Efficiency | 82% | |
| Power (Watts) - Max | 6W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ITX2405S | |
| Related Links | ITX2, ITX2405S Datasheet, XP Power Distributor | |
