IXYS Corporation IXFP5N50PM
- Mfg. Part Number
- IXFP5N50PM
- Manufacturer
- IXYS Corporation
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 500V 3.2A TO-220
- Datasheet Download
- IXFP5N50PM.pdf
Availability of IXFP5N50PM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.26000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IXFP5N50PM, we specialize in IXYS Corporation all series electronic components. IXFP5N50PM can be shipped within 24 hours after order. If you have any demands for IXFP5N50PM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IXFP5N50PM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IXFP5N50PM
| Internal Part Number | EIS-IXFP5N50PM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | HiPerFET™, PolarHT™ | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 500V | |
| Current - Continuous Drain (Id) @ 25°C | 3.2A (Tc) | |
| Rds On (Max) @ Id, Vgs | 1.4 Ohm @ 2.5A, 10V | |
| Vgs(th) (Max) @ Id | 5.5V @ 500µA | |
| Gate Charge (Qg) @ Vgs | 12.6nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 620pF @ 25V | |
| Power - Max | 38W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220AB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IXFP5N50PM | |
| Related Links | IXFP5, IXFP5N50PM Datasheet, IXYS Corporation Distributor | |
IXFP5N50PM Details Description
