IXYS Corporation IXTF230N085T
- Mfg. Part Number
- IXTF230N085T
- Manufacturer
- IXYS Corporation
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 85V 130A ISOPLUS I4
- Datasheet Download
- IXTF230N085T.pdf
Availability of IXTF230N085T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IXTF230N085T, we specialize in IXYS Corporation all series electronic components. IXTF230N085T can be shipped within 24 hours after order. If you have any demands for IXTF230N085T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IXTF230N085T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IXTF230N085T
| Internal Part Number | EIS-IXTF230N085T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | IXT Series 30/Oct/2012 | |
| Standard Package | 25 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | TrenchMV™ | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 85V | |
| Current - Continuous Drain (Id) @ 25°C | 130A (Tc) | |
| Rds On (Max) @ Id, Vgs | 5.3 mOhm @ 50A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250mA | |
| Gate Charge (Qg) @ Vgs | 187nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 9900pF @ 25V | |
| Power - Max | 200W | |
| Mounting Type | Through Hole | |
| Package / Case | i4-Pac™-5 | |
| Supplier Device Package | ISOPLUS i4-PAC™ | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IXTF230N085T | |
| Related Links | IXTF23, IXTF230N085T Datasheet, IXYS Corporation Distributor | |
