IXYS Corporation IXTH15N50L2
- Mfg. Part Number
- IXTH15N50L2
- Manufacturer
- IXYS Corporation
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 500V 15A TO-247
- Datasheet Download
- IXTH15N50L2.pdf
Availability of IXTH15N50L2
Available Quantity
5027 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.93600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IXTH15N50L2, we specialize in IXYS Corporation all series electronic components. IXTH15N50L2 can be shipped within 24 hours after order. If you have any demands for IXTH15N50L2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IXTH15N50L2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IXTH15N50L2
| Internal Part Number | EIS-IXTH15N50L2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Linear L2™ MOSFETs | |
| Standard Package | 30 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | Linear L2™ | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 500V | |
| Current - Continuous Drain (Id) @ 25°C | 15A (Tc) | |
| Rds On (Max) @ Id, Vgs | 480 mOhm @ 7.5A, 10V | |
| Vgs(th) (Max) @ Id | 4.5V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 123nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 4080pF @ 25V | |
| Power - Max | 300W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-247-3 | |
| Supplier Device Package | TO-247 (IXTH) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IXTH15N50L2 | |
| Related Links | IXTH1, IXTH15N50L2 Datasheet, IXYS Corporation Distributor | |
IXTH15N50L2 Details Description
