Souriau Connection Technology JBXFD3G22MCSDSR019
- Mfg. Part Number
- JBXFD3G22MCSDSR019
- Manufacturer
- Souriau Connection Technology
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 22POS INLINE PIN CRIMP
- Datasheet Download
- JBXFD3G22MCSDSR019.pdf
Availability of JBXFD3G22MCSDSR019
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 83.77760
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JBXFD3G22MCSDSR019, we specialize in Souriau Connection Technology all series electronic components. JBXFD3G22MCSDSR019 can be shipped within 24 hours after order. If you have any demands for JBXFD3G22MCSDSR019, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JBXFD3G22MCSDSR019 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JBXFD3G22MCSDSR019
| Internal Part Number | EIS-JBXFD3G22MCSDSR019 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | JBX | |
| Packaging | Bulk | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 22 | |
| Shell Size - Insert | 3 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Push-Pull | |
| Orientation | G | |
| Ingress Protection | IP40 | |
| Shell Material, Finish | Brass, Chrome over Nickel | |
| Contact Finish | Gold | |
| Features | Cable Clamp, Shielded | |
| Contact Finish Thickness | 19.7µin (0.50µm) | |
| Current Rating | 5.5A | |
| Voltage - Rated | 560VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JBXFD3G22MCSDSR019 | |
| Related Links | JBXFD3G22, JBXFD3G22MCSDSR019 Datasheet, Souriau Connection Technology Distributor | |
JBXFD3G22MCSDSR019 Details Description
