XP Power JCD0412D24
- Mfg. Part Number
- JCD0412D24
- Manufacturer
- XP Power
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER +/-24V 4W
- Datasheet Download
- JCD0412D24.pdf
Availability of JCD0412D24
Available Quantity
5030 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.20998
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JCD0412D24, we specialize in XP Power all series electronic components. JCD0412D24 can be shipped within 24 hours after order. If you have any demands for JCD0412D24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JCD0412D24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JCD0412D24
| Internal Part Number | EIS-JCD0412D24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | JCD | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 9V | |
| Voltage - Input (Max) | 18V | |
| Voltage - Output 1 | 24V | |
| Voltage - Output 2 | -24V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 83mA | |
| Power (Watts) - Manufacture Series | 4W | |
| Voltage - Isolation | 1.6kV (1600V) | |
| Features | OCP, OVP, SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP Module (8 Leads) | |
| Size / Dimension | 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.4mm) | |
| Operating Temperature | -40°C ~ 100°C | |
| Efficiency | 80% | |
| Power (Watts) - Max | 4W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JCD0412D24 | |
| Related Links | JCD04, JCD0412D24 Datasheet, XP Power Distributor | |
JCD0412D24 Details Description
