XP Power JCE0348D15
- Mfg. Part Number
- JCE0348D15
- Manufacturer
- XP Power
- Product Category
- DC DC Converters
- Brief Description
- DC-DC 3W 2:1 INPUT DIP24 DUAL
- Datasheet Download
- JCE0348D15.pdf
Availability of JCE0348D15
Available Quantity
5040 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.25900
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JCE0348D15, we specialize in XP Power all series electronic components. JCE0348D15 can be shipped within 24 hours after order. If you have any demands for JCE0348D15, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JCE0348D15 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JCE0348D15
| Internal Part Number | EIS-JCE0348D15 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | JCE03 | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 15V | |
| Voltage - Output 2 | -15V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 100mA, 100mA | |
| Power (Watts) - Manufacture Series | 3W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP Module (8 Leads) | |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) | |
| Operating Temperature | -40°C ~ 100°C | |
| Efficiency | 81% | |
| Power (Watts) - Max | 3W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JCE0348D15 | |
| Related Links | JCE03, JCE0348D15 Datasheet, XP Power Distributor | |
JCE0348D15 Details Description
