GE Critical Power JHW050AF
- Mfg. Part Number
- JHW050AF
- Manufacturer
- GE Critical Power
- Product Category
- DC DC Converters
- Brief Description
- CONVERT DC/DC 5/3.3V OUT T/H
- Datasheet Download
- JHW050AF.pdf
Availability of JHW050AF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JHW050AF, we specialize in GE Critical Power all series electronic components. JHW050AF can be shipped within 24 hours after order. If you have any demands for JHW050AF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JHW050AF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JHW050AF
| Internal Part Number | EIS-JHW050AF | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | Power Module Wizard™ | |
| Standard Package | 27 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | JHW050 | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | 3.3V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 8A, 8A | |
| Power (Watts) - Manufacture Series | 50W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | Remote On/Off, OCP, OTP, OVP | |
| Mounting Type | Through Hole | |
| Package / Case | 11-DIP Module | |
| Size / Dimension | 2.38" L x 2.26" W x 0.33" H (60.5mm x 57.4mm x 8.4mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 89% | |
| Power (Watts) - Max | 50W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JHW050AF | |
| Related Links | JHW0, JHW050AF Datasheet, GE Critical Power Distributor | |
