XP Power JTC0624S3V3
- Mfg. Part Number
- JTC0624S3V3
- Manufacturer
- XP Power
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 3.3V 6W
- Datasheet Download
- JTC0624S3V3.pdf
Availability of JTC0624S3V3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 31.96000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JTC0624S3V3, we specialize in XP Power all series electronic components. JTC0624S3V3 can be shipped within 24 hours after order. If you have any demands for JTC0624S3V3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JTC0624S3V3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JTC0624S3V3
| Internal Part Number | EIS-JTC0624S3V3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | JTC | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 9V | |
| Voltage - Input (Max) | 36V | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 1.4A | |
| Power (Watts) - Manufacture Series | 6W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP Module (7 Leads) | |
| Size / Dimension | 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.4mm) | |
| Operating Temperature | -40°C ~ 100°C | |
| Efficiency | 76% | |
| Power (Watts) - Max | 5W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JTC0624S3V3 | |
| Related Links | JTC06, JTC0624S3V3 Datasheet, XP Power Distributor | |
