XP Power JTL4048D12
- Mfg. Part Number
- JTL4048D12
- Manufacturer
- XP Power
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER +/-12V 40W
- Datasheet Download
- JTL4048D12.pdf
Availability of JTL4048D12
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 86.33000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JTL4048D12, we specialize in XP Power all series electronic components. JTL4048D12 can be shipped within 24 hours after order. If you have any demands for JTL4048D12, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JTL4048D12 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JTL4048D12
| Internal Part Number | EIS-JTL4048D12 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | JTL | |
| Packaging | Tube | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 18V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 12V | |
| Voltage - Output 2 | -12V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 1.65A, 1.65A | |
| Power (Watts) - Manufacture Series | 40W | |
| Voltage - Isolation | 1.6kV (1600V) | |
| Features | Remote On/Off, OCP, OVP, SCP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP Module | |
| Size / Dimension | 2.00" L x 2.00" W x 0.40" H (50.8mm x 50.8mm x 10.2mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 90% | |
| Power (Watts) - Max | 40W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JTL4048D12 | |
| Related Links | JTL40, JTL4048D12 Datasheet, XP Power Distributor | |
JTL4048D12 Details Description
