TDK-Lambda Americas, Inc. JWS3003
- Mfg. Part Number
- JWS3003
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 3.3V 300W
- Datasheet Download
- JWS3003.pdf
Availability of JWS3003
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 452.37000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JWS3003, we specialize in TDK-Lambda Americas, Inc. all series electronic components. JWS3003 can be shipped within 24 hours after order. If you have any demands for JWS3003, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JWS3003 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JWS3003
| Internal Part Number | EIS-JWS3003 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | JWS | |
| Type | Enclosed | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 265 VAC | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 60A | |
| Power (Watts) | 300W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 68% | |
| Operating Temperature | -10°C ~ 65°C (With Derating) | |
| Features | Adjustable Output, DC Input Capable, PFC, Remote Sense, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 7.48" L x 4.72" W x 3.62" H (190.0mm x 120.0mm x 92.0mm) | |
| Minimum Load Required | - | |
| Approvals | CE | |
| Power (Watts) - Max | 198W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JWS3003 | |
| Related Links | JWS, JWS3003 Datasheet, TDK-Lambda Americas, Inc. Distributor | |
JWS3003 Details Description
