E-Switch KAP1102VT
- Mfg. Part Number
- KAP1102VT
- Manufacturer
- E-Switch
- Product Category
- DIP Switches
- Brief Description
- SW DIP PIANO SPST 2 POS SEALED
- Datasheet Download
- KAP1102VT.pdf
Availability of KAP1102VT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.90560
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KAP1102VT, we specialize in E-Switch all series electronic components. KAP1102VT can be shipped within 24 hours after order. If you have any demands for KAP1102VT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KAP1102VT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KAP1102VT
| Internal Part Number | EIS-KAP1102VT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | KAP Series RoHS Cert of Compliance | |
| Standard Package | 65 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | KAP | |
| Packaging | Tube | |
| Circuit | SPST | |
| Number of Positions | 2 | |
| Current Rating | 25mA | |
| Voltage Rating | 24VDC | |
| Actuator Type | Piano | |
| Actuator Level | Flush, Recessed | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Height Above Board | 0.402" (10.20mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Pitch | 0.100" (2.54mm), Full | |
| Washable | Yes | |
| Features | Tape Seal | |
| Body Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Length | 0.261" (6.63mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Mechanical Life | 2,000 Cycles | |
| Electrical Life | 2,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KAP1102VT | |
| Related Links | KAP1, KAP1102VT Datasheet, E-Switch Distributor | |
