NKK Switches KB02KW01-12-CC
- Mfg. Part Number
- KB02KW01-12-CC
- Manufacturer
- NKK Switches
- Product Category
- Panel Indicators, Pilot Lights
- Brief Description
- INDICATOR
- Datasheet Download
- KB02KW01-12-CC.pdf
Availability of KB02KW01-12-CC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.46000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KB02KW01-12-CC, we specialize in NKK Switches all series electronic components. KB02KW01-12-CC can be shipped within 24 hours after order. If you have any demands for KB02KW01-12-CC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KB02KW01-12-CC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KB02KW01-12-CC
| Internal Part Number | EIS-KB02KW01-12-CC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Optoelectronics | |
| Family | Panel Indicators, Pilot Lights | |
| Series | KB | |
| Type | Incandescent | |
| Lamp Color | Red | |
| Lens Color | Red | |
| Lens Transparency | Diffused | |
| Ratings | Vf (Typ), If (Max) | |
| Voltage | 12V | |
| Current | 60mA | |
| Panel Cutout Shape | Round | |
| Panel Cutout Dimensions | 0.48" (12.19mm) | |
| Lens Style/Size | Round with Flat Top, 11.60mm | |
| Millicandela Rating | - | |
| Wavelength - Peak | - | |
| Viewing Angle | - | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KB02KW01-12-CC | |
| Related Links | KB02KW0, KB02KW01-12-CC Datasheet, NKK Switches Distributor | |
KB02KW01-12-CC Details Description
