ITT Cannon, LLC KJB7T23W21PCL
- Mfg. Part Number
- KJB7T23W21PCL
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors - Housings
- Brief Description
- CONN HSG RCPT 21POS JAM NUT PIN
- Datasheet Download
- KJB7T23W21PCL.pdf
Availability of KJB7T23W21PCL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 56.83420
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KJB7T23W21PCL, we specialize in ITT Cannon, LLC all series electronic components. KJB7T23W21PCL can be shipped within 24 hours after order. If you have any demands for KJB7T23W21PCL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KJB7T23W21PCL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KJB7T23W21PCL
| Internal Part Number | EIS-KJB7T23W21PCL | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Housings | |
| Series | MIL-DTL-38999 Series III, KJB | |
| Packaging | Bulk | |
| Connector Type | Receptacle for Male Contacts | |
| Number of Positions | 21 | |
| Shell Size - Insert | 23-21 | |
| Shell Size, MIL | - | |
| Contact Type | Crimp | |
| Contact Size | 16 | |
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
| Fastening Type | Threaded | |
| Orientation | C | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Ingress Protection | Environment Resistant | |
| Features | - | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KJB7T23W21PCL | |
| Related Links | KJB7T2, KJB7T23W21PCL Datasheet, ITT Cannon, LLC Distributor | |
