Fairchild Semiconductor KSK596PCWD
- Mfg. Part Number
- KSK596PCWD
- Manufacturer
- Fairchild Semiconductor
- Product Category
- JFETs (Junction Field Effect)
- Brief Description
- JFET N-CH 20V 0.1W TO-92S
- Datasheet Download
- KSK596PCWD.pdf
Availability of KSK596PCWD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KSK596PCWD, we specialize in Fairchild Semiconductor all series electronic components. KSK596PCWD can be shipped within 24 hours after order. If you have any demands for KSK596PCWD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KSK596PCWD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KSK596PCWD
| Internal Part Number | EIS-KSK596PCWD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | JFETs (Junction Field Effect) | |
| Series | - | |
| Packaging | Bulk | |
| FET Type | N-Channel | |
| Voltage - Breakdown (V(BR)GSS) | 20V | |
| Drain to Source Voltage (Vdss) | - | |
| Current - Drain (Idss) @ Vds (Vgs=0) | 100µA @ 5V | |
| Current Drain (Id) - Max | 1mA | |
| Voltage - Cutoff (VGS off) @ Id | 600mV @ 1µA | |
| Input Capacitance (Ciss) @ Vds | 3.5pF @ 5V | |
| Resistance - RDS(On) | - | |
| Mounting Type | Through Hole | |
| Package / Case | TO-226-3, TO-92-3 Short Body | |
| Supplier Device Package | TO-92S | |
| Power - Max | 100mW | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KSK596PCWD | |
| Related Links | KSK59, KSK596PCWD Datasheet, Fairchild Semiconductor Distributor | |
KSK596PCWD Details Description
