ON Semiconductor LB1836ML-MPB-E
- Mfg. Part Number
- LB1836ML-MPB-E
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Full, Half-Bridge Drivers
- Brief Description
- IC MOTOR DRIVER
- Datasheet Download
- LB1836ML-MPB-E.pdf
Availability of LB1836ML-MPB-E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.91000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LB1836ML-MPB-E, we specialize in ON Semiconductor all series electronic components. LB1836ML-MPB-E can be shipped within 24 hours after order. If you have any demands for LB1836ML-MPB-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LB1836ML-MPB-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LB1836ML-MPB-E
| Internal Part Number | EIS-LB1836ML-MPB-E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 24/Jul/2015 | |
| Standard Package | 60 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Full, Half-Bridge Drivers | |
| Series | - | |
| Packaging | Tube | |
| Output Configuration | Half Bridge (4) | |
| Applications | DC Motors, General Purpose | |
| Interface | Logic | |
| Load Type | Inductive | |
| Technology | Bipolar | |
| Rds On (Typ) | - | |
| Current - Output / Channel | 1A | |
| Current - Peak Output | - | |
| Voltage - Supply | 2.5 V ~ 9 V | |
| Voltage - Load | 1.8 V ~ 9 V | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Features | - | |
| Fault Protection | Over Temperature | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-LSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 14-MFPS | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LB1836ML-MPB-E | |
| Related Links | LB1836M, LB1836ML-MPB-E Datasheet, ON Semiconductor Distributor | |
LB1836ML-MPB-E Details Description
