NKK Switches LB25WKG01-05-JC
- Mfg. Part Number
- LB25WKG01-05-JC
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 0.4VA 28V
- Datasheet Download
- LB25WKG01-05-JC.pdf
Availability of LB25WKG01-05-JC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 19.21000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LB25WKG01-05-JC, we specialize in NKK Switches all series electronic components. LB25WKG01-05-JC can be shipped within 24 hours after order. If you have any demands for LB25WKG01-05-JC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LB25WKG01-05-JC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LB25WKG01-05-JC
| Internal Part Number | EIS-LB25WKG01-05-JC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | 3D CAD Models | |
| Featured Product | Pushbutton Switches | |
| 3D Model | LB25WKG01-05-JC | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | LB | |
| Packaging | Bulk | |
| Type | Standard, Illuminated | |
| Circuit | DPDT | |
| Switch Function | On-Mom | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 28V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Round, Button | |
| Color - Actuator/Cap | Clear (Red Filter/Diffuser) | |
| Illumination Type, Color | Incandescent, Red | |
| Illumination Voltage (Nominal) | 5 VAC | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 22.00mm Dia | |
| Operating Temperature | -25°C ~ 50°C | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 100,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LB25WKG01-05-JC | |
| Related Links | LB25WKG, LB25WKG01-05-JC Datasheet, NKK Switches Distributor | |
LB25WKG01-05-JC Details Description
