Lattice Semiconductor Corporation LC4064ZC-5TN48C
- Mfg. Part Number
- LC4064ZC-5TN48C
- Manufacturer
- Lattice Semiconductor Corporation
- Product Category
- Embedded - CPLDs (Complex Programmable Logic Devices)
- Brief Description
- IC CPLD 64MC 5NS 48TQFP
- Datasheet Download
- LC4064ZC-5TN48C.pdf
Availability of LC4064ZC-5TN48C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.47187
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LC4064ZC-5TN48C, we specialize in Lattice Semiconductor Corporation all series electronic components. LC4064ZC-5TN48C can be shipped within 24 hours after order. If you have any demands for LC4064ZC-5TN48C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LC4064ZC-5TN48C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LC4064ZC-5TN48C
| Internal Part Number | EIS-LC4064ZC-5TN48C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Multiple Devices Cu Wire 01/Jul/2013 | |
| PCN Assembly/Origin | Alternate Assembly Revision B 17/Nov/2014 Alternate Assembly/Test Site 06/Oct/2014 Alternate Assembly Revision B 17/Nov/2014 Alternate Assembly/Test Site 14/Apr/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) | |
| Series | ispMACH® 4000Z | |
| Packaging | Tray | |
| Programmable Type | In System Programmable | |
| Delay Time tpd(1) Max | 5.0ns | |
| Voltage Supply - Internal | 1.7 V ~ 1.9 V | |
| Number of Logic Elements/Blocks | 4 | |
| Number of Macrocells | 64 | |
| Number of Gates | - | |
| Number of I/O | 32 | |
| Operating Temperature | 0°C ~ 90°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 48-LQFP | |
| Supplier Device Package | 48-TQFP (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LC4064ZC-5TN48C | |
| Related Links | LC4064Z, LC4064ZC-5TN48C Datasheet, Lattice Semiconductor Corporation Distributor | |
LC4064ZC-5TN48C Details Description
