Littelfuse LCE7.5
- Mfg. Part Number
- LCE7.5
- Manufacturer
- Littelfuse
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 7.5VWM 13.55VC DO201
- Datasheet Download
- LCE7.5.pdf
Availability of LCE7.5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LCE7.5, we specialize in Littelfuse all series electronic components. LCE7.5 can be shipped within 24 hours after order. If you have any demands for LCE7.5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LCE7.5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LCE7.5
| Internal Part Number | EIS-LCE7.5 | |
| Lead Free Status / RoHS Status | Lead free by exemption / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Transient Voltage Suppression (TVS) Diodes | |
| Standard Package | 1,200 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | LCE | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 7.5V | |
| Voltage - Breakdown (Min) | 7.89V | |
| Voltage - Clamping (Max) @ Ipp | 13.55V | |
| Current - Peak Pulse (10/1000µs) | 100A | |
| Power - Peak Pulse | 1500W (1.5kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 175°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | DO-201AA, DO-27, Axial | |
| Supplier Device Package | DO-201 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LCE7.5 | |
| Related Links | LCE, LCE7.5 Datasheet, Littelfuse Distributor | |
LCE7.5 Details Description
