Artesyn Embedded Technologies LES20A24-3V3AJ
- Mfg. Part Number
- LES20A24-3V3AJ
- Manufacturer
- Artesyn Embedded Technologies
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 3.3V 100W
- Datasheet Download
- LES20A24-3V3AJ.pdf
Availability of LES20A24-3V3AJ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LES20A24-3V3AJ, we specialize in Artesyn Embedded Technologies all series electronic components. LES20A24-3V3AJ can be shipped within 24 hours after order. If you have any demands for LES20A24-3V3AJ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LES20A24-3V3AJ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LES20A24-3V3AJ
| Internal Part Number | EIS-LES20A24-3V3AJ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 64 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | Typhoon | |
| Packaging | Tray | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 18V | |
| Voltage - Input (Max) | 36V | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 20A | |
| Power (Watts) - Manufacture Series | 100W | |
| Voltage - Isolation | 2.25kV (2250V) | |
| Features | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP Module, 1/8 Brick | |
| Size / Dimension | 2.30" L x 0.90" W x 0.19" H (58.4mm x 22.9mm x 4.8mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 90% | |
| Power (Watts) - Max | 66W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LES20A24-3V3AJ | |
| Related Links | LES20A2, LES20A24-3V3AJ Datasheet, Artesyn Embedded Technologies Distributor | |
LES20A24-3V3AJ Details Description
